AD2206 D2

$169.00

  • 150W – 400W optimal power range
  • 2″ voice coil diameter
  • Designed for use in small vented enclosures.
  • Engineered in the USA.

Description

Fs	51.510 Hz
Qms	5.989
Vas	2.108 l
Cms	0.072 mm/N
Mms	130.400 g
Rms	7.121 kg/s
Dia	135.000 mm
Sd	143.138 cm²

Qes	0.795
Re	4.244 Ω
Le	1.646 mH
Z	5.092 Ω
Bl	15.002 Tm
Bl²/Re	53.032 N²/W

Qts	0.702
no	0.034 %
SPL	77.576 dB
EBP	64.727

Nominal Diameter		6.5 in
Overall Diameter		7.16 in / 182 mm
Mounting Hole Diameter		5.90 in / 150 mm
Bolt Hole Circle Diameter
Motor Outer Diameter            5.74 in / 146 mm
Mounting Depth			4.72 in / 120 mm
Required Pole Vent Clearance
Driver Displacement		 cu ft / l

Minimum Sealed Volume		N/A
Minimum Vented Volume		TBA

* Tune for desired response

Please visit our Enclosure Design Service page for custom designs.
