Description
Every X Series amplifier undergoes testing before it is packaged to confirm they work as intended. First, the crossover functions and a clean high output sine wave are confirmed to be within specification. Then, the amplifier is wired to a resistor bank and driven with a very high signal to drive the amp into thermal protection. The amp is cycled back on and is again tested for a clean high output sine wave.
| Continuous Power | 2900W x 1 @ 4 ohms |
| At 14.4V Supply Voltage | 5300W x 1 @ 2 ohms |
| 8000W x 1 @ 1 ohm | |
| Frequency Response | 13Hz – 269Hz |
| Input Sensitivity | 0.4V to 6V |
| Fuse Ratings | 250A @ 4 ohms / 500A @ 2 ohms / 720A @ 1 ohm |
| Filter Modes | Subsonic and Low Pass |
| Subsonic Filter @ 24dB/Oct | 10Hz – 50Hz |
 Linkwitz-Riley |
|
| Low Pass Filter @ 24dB/Oct | 35Hz – 250Hz |
| Linkwitz-Riley |
|
| Detented Filter Potentiometers | 41 Click-in-Place Frequencies |
| Remote Level Control w/ Clip Indicator / Thermal / Voltage | Included |
| Pass-Through Output | Yes |
| Height | 3.12 in / 79.3 mm |
| Width | 10.59 in / 269 mm |
| Length (Heat Sink) | 23.62 in / 600 mm |
| Net Weight | 38 lb /17.24 kg |
