Description
The 3000 series 15 employs a finely-tuned balance of damping and extensive motor force to achieve very high efficiency, offering exceptional versatility and unmatched performance in a variety of real-world functions.
Dual 2 ohm
Fs 29.17 Hz
Qms 7.787
Vas 48.22 liters
Cms 0.059 mm/N
Mms 508.10 g
Rms kg/s
Dia 312.2 mm
Sd sq cm
Qes 0.6532
Re 4.251 ohms
Le 4.555 mH
Z ohms
BL 24.62 Tm
Qts 0.6026
no 0.1747 %
SPL 84.52 dB
EBP 44.66
Dual 4 ohm
Fs 31.02 Hz
Qms 6.893
Vas 50.55 liters
Cms 0.061 mm/N
Mms 428.6 g
Rms kg/s
Dia 312.2 mm
Sd sq cm
Qes 0.7031
Re 6.99 ohms
Le 6.132 mH
Z ohms
BL 28.82 Tm
Qts 0.638
no 0.2046 %
SPL 85.21 dB
EBP 44.12
XMax 16.5mm
Nominal Diameter 15in
Overall Diameter 15.6in / 396mm
Mounting Hole Diameter 14.12in / 358.65mm
Motor Outer Diameter 7.48in / 190mm
Mounting Depth 8.06in / 205mm
Driver Displacement 0.16 cu ft / 4.273 l
Minimum Sealed Volume
Minimum Vented Volume cu ft / l net*
* Tune for desired response
